Getting started

Workflow

To load a form, the Form Manager is instructed to create a form. The Form Manager passes the request to the Data Store. The Data Store establishes a connection to the database and downloads the form template and returns it to the Form Manager. The Form Parser is requested to convert the form template into a form. The converted form is returned via the Form Manager.

Workflow of dynamic form

The workflow to load a form from a data store.

Components

Dynamic form consists of four components:

  1. Form Manager

  2. Data Store

  3. Form Parser

  4. Template Builder

There are interfaces for Data Store and Form Parser. This allows any combination of data sources and form types. The corresponding implementations are passed to the Form Manager. All concrete implementation of the data store and the form parser have to inherit from their abstract base classes: dynamic_form.interfaces.IDataStore and dynamic_form.interfaces.IFormParser, respectively.

Form Manager

The FormManager is the controller of this package. It is his job to load and save forms from and to a data store. It can be found in dynamic_form.form_manager.FormManager. The constructor of the FormManager expects two arguments: a data store and a form parser. If the data store contains a form, we load it through the form manager by the form’s name.

from pymongo import MongoClient
from dynamic_form import FormManager, MongoDataStore, JsonFlaskParser

client = MongoClient()
form_manager = FormManager(
                    data_store=MongoDataStore(client["database"]["collection"]),
                    input_parser=JsonFlaskParser())

form_manager.get_form("signup")

Data Store

The data store serves as the interface to the underlying data store. It is responsible to fetch and dump forms in the data store representation.

Form Parser

The form parser is responsible to convert form templates from the data store into forms.
